Repair manual: Electric drive motor 1700 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D

Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-

10. Electric drive motor 1700

10.1 Overview

Pos. Description

a Speed sensor

b Connection, motor cables

c Motor: S212L/214/214L/220D 1.5kW

c Motor: S210/212/212S 1.0kW

e Temperature sensor
