Repair manual: Brake system/Wheels C3000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D

Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-

12.7 Castor wheels 3540

12.7.1 Overview

Pos. Description Pos. Description

A Circlip H Screw

B Washer I Spacer

C Screw J Spacer

D Bracket K Bearings

E Nut L Guard

F Bearings M Nut

G Circlip

L M
