Citation SERVICE BULLETIN
SB560-34-114
TOOLING
NAME NUMBER MANUFACTURER USE
Transponder Test Set ATC-601 software
version 2.22
or
Equivalent
IFR Systems Incorporated
10200 West Yor
kStreet
Wichita, KS 67125
To test Mode S transponders.
TCAS Test Set TCAS-201 IFR Systems Incorporated
10200 West Yor
kStreet
Wichita, KS 67125
To test TCAS II.
Air Data Test Set Model 6520 or
equivalent
Labersab Incorporated
10435 Greenbo
ugh Suite 300
Stafford, TX 77477
To t est pitot-static systems.
Squat Switch Simu-
lator
6588006-1 Cessna Citation Parts Distribution
7121 Southwes
tBoulevard
Wichita, KS 67215
To simulate airplane ground
and air modes.
Laptop Personal
Computer
Commercially available To program the TCAS II
configuratio
n module.
RS232 diagnostic
connector
Commercially available To connect the personal
computer to the RS232
comm port con
nection.
Radio Altimeter Sim-
ulator
Commercially available To simulate radio altimeter
altitiudes.
CHANGE IN WEIGHT AND BALANCE
Weigh the airplane after modification to calculate weight and balance information.
REFERENCES
Cessna Model 560 Maintenance Manual
Order the following engineering drawings. The latest revision and all applicable drawing change notices
for each document must be used.
MAIN TCAS II INSTALLATION ENGINEERING D RAWING LIST
DOCUMENT NUMBER
TITLE
9690561
DUAL MODE-S TRANSPONDERS SYST EM
PROGRAMMING
9608042
UPPER BENDIX TCAS A NTENNA INSTL
9608043
LOWER BENDIX TCAS ANTENNA INSTL
9608044
TRANSPONDER LOWER ANTENNA INSTL
9690536
TCAS II SYSTEM PROGRAMMING
9690476
TEST PORT INSTL-MOD TCAS II
9690574 FEED THRU PLATE FOR TCAS
9690575
TCAS II INSTRUMENT PANEL MOD
9690583
P1000 HARDWARE UPGRADE FOR TCAS
CAPABILITY-MOD
Aug 13/2004 560-34-114
Revision 2 - Jan 2/2007 Page 5
