(3) Record the received values in Table 2.
M. TCAS II / ACAS II Resolution Advisory Discrete and Flight Status:
(1) Set the ATC-601 Ramp Test Unit to Aircraft Operation Status.
(2) Make sure that the Subtype states proper Airborne/Ground Status (Note: Airborne due to
Weight on Wheels logic).
(3) Make sure that TCAS RA states: YES.
(4) Record the received values in Table 2.
Table 2
TEST CONDITION
PARAMETER
EXPECTED VALUE RECEIVED VALUE
Aircaft ID XXXXX
Flight ID 01560649
Flight ID 02560649
Aircaft ID
Recieved within 5
seconds
PASS
Altitude
Recorded from the
Pilot's EFIS display -
should match air data
test set values.
Pressure Altitude
Mode A 1200
XPDR Level 2-4
SI Capability YES
Aircraft ID Capability YES
Squitter Capability NO
Capability Report
Common Use GICB
Report
YES
ARA NOT 00000000000000 *
TCAS RA
RI Field
3=TCASwithVertical
Guidance
NOTE: * Multiple possible values exist for the resolution advisory field on the ATC-601, depending
on the test aircraft altitude and the intruder altitude. Confirm that the field changes from all
zeros as the test aircraft gives an audible resolution advisory.
12. Do a functional check of the TCAS II system.
A. Start the TCASDIAG program.
B. Set the configuration module as follows:
(1) From the main menu screen select “Config Mod” from the top menu. Select “Initialize Config
Module” and choose “Yes” to continue initialization of the module. Configure each option per
the TCAS II configuration procedure. Press “OK” after configuring all options. Press “OK”
Aug 13/2004 560-34-114
Revision 2 - Jan 2/2007 Page 17
