5.3.1 Connect with 51.2Vdc Inverter
To prevent the battery from moving, make sure the battery is properly installed
.
If the battery is installed above the floor or on a platform, make sure that the wall or
platform is capable of supporting the battery’s weight.
5.3.1.1 Wall mounting
1.Use the positioning cardboard to determine the
bracket mounting place.
2.Drill holes in the wall for the M8 expansion screw
anchors, of which depth should be at least 50 mm.
Tighten the screws to a torque around 2.5 N
∙
m.
3.Fasten the battery to bracket fastening hole with M6
screws with 2.0N∙m roughly.
4.Meanwhile, two or four batteries could be installed by
these brackets.
Note: if more than 4 batteries are to be installed, a cabinet is recommended to be selected
