SAM-3000 / SAM-1950

Revision 1.0– Issue September 2015

5.4 Gas flow schematic

A exemplary gas diagram is shown below:

25-250 l/h

6-60 l/h

25-250 l/h

SAM-3000

sample gas 1

25-250 l/h

to analyser

ATM

example

sample gas 2

sample gas 3

sample gas 4

zero gas

span gas
