58/79
E
Product:
SAM-3000 /SAM-1950
Revision 1.0 – Issue September 2015
Micro-fuse
Power supply 24 VDC
Connection to analyzer SUB-D 9-pin
Connection to DCS SUB-D 37-pin
1
3
2
4
1
3
2
4
5.5.3 Design of both Control PCBs (back view)
