Challenge Xtreme 18V CORDLESS HAMMER DRILL User Manual

13
Switch lock
The switch trigger can be locked in the OFF position. This helps to reduce the
possibility of accidental starting when not in use. To lock the switch trigger, place the
direction of Forward/Reverse rotating control in the center position by pushing the
direction buttons on either side of the drill.
Reversible(See Fig. C1&C2)
For drilling and screw driving use forward rotation marked “ ”(lever is moved to
the left). Only use reverse rotation marked “ ” (lever is moved to the right) to
remove screws or release a jammed drill bit.
Warning: Never change the direction of rotation when the chuck is rotating, Wait
until it has stopped.
Depress to start and release to stop your drill.
It is also a variable speed switch that delivers higher speed and torque with
increased trigger pressure. Speed is controlled by the amount of switch trigger
depression.
Warning: Do not operate for long periods at low speed because excess heat will be
produced internally.
Operation Instructions
On/Off switch
Fig.C1 Fig.C2
Customer Helpline 0345 640 0800

Challenge Xtreme 18V CORDLESS HAMMER DRILL Specifications

General

Brand	Challenge Xtreme
Model	18V CORDLESS HAMMER DRILL
Category	Drill
Language	English
