Challenge Xtreme 18V CORDLESS HAMMER DRILL User Manual

15
(Screw driving force of your drill driver) The torque is adjusted by rotating the torque
adjustment ring. The torque is greater when the torque adjustment ring is set on a
higher setting. The torque is less when the torque adjustment ring is set on a lower setting.
Make the setting as follows:
1 – 22 for driving l screws
for heavy drilling
for drilling in masonry
Operation Instructions
Torque adjustment(See Fig. F)
Fig.F
The drill has a two-speed gear control designed for drilling or driving at Low (mark is 1)
or High (mark is 2) speeds. A slide switch is located on top of the drill to select either
Low or High speed.
When using the drill in the Low speed range, the speed will decrease and the drill will
have greater power and torque. When using the drill in the High speed range, the speed
will increase and the drill will have less power and torque.
Gear I
Low speed range: for screwdriving or working with large drilling diameter
Gear II
High speed range: for working with small drilling diameter
Note: Please switch off the drill before switch the two-speed gear control or the drill may
be damaged.
Two-speed gear control (See Fig. G)
