547095D1 C Rev A-13
SAFETY
FIG. 13: Use caution when refueling a machine. Do not
smoke while refueling and do not refuel near open flames
or sparks. Always stop engine before refueling. Fill fuel
tank outdoors.
Fire Extinguisher
FIG. 14: Make sure that a fire extinguisher is available
and be familiar with operation. Inspect and service fire
extinguisher regularly, and obey recommendations on
instruction plate.
An optional mounting bracket (1) can be installed on right
front frame rail.
Bracket is designed to hold a 4.5 kg (10 lb) extinguisher.
Do not weld a bracket on cab ROPS frame to install fire
extinguisher.
Do not drill holes in cab ROPS frame to mount fire
extinguisher on the ROPS.
Make sure all clamps, guards, and heat shields are
installed correctly to prevent vibration, rubbing, and
excessive heat during operation.
FIG. 13
FIG. 14
