547095D1 C Rev A-15
SAFETY
Side View
FIG. 15: Side View
FIG. 16: Warning - Radar Unit (1)
The safety sign is located on outside of frame rails on both
sides.
Do not look directly into face of ground speed sensor
while in operation. Eye injury may occur from low intensity
microwave signal emitted.
FIG. 15
S092211001
4
2
1
3
6
5
FIG. 16
511090D1 01
R
A
D
A
R
R
A
D
A
R
0125
