SAFETY
Front View
FIG. 26: Front View
FIG. 27: Warning - Battery Explosion Hazard (1)
The safety sign is located on front frame of machine and
on hold down bracket for batteries.
Improper jumper cable connections can cause explosion
resulting in personal injury.When using jumper cables,
always connect positive (+) cable, from external source, to
positive (+) jump start post and negative (-) cable, from
external source, to engine block or frame.
Remove negative cable (s) from battery(s) before
removing starter solenoid cover and before servicing
electrical system.
FIG. 26
FIG. 27
