Chamberlain 041D8071-4 User Manual

2
1 Disconnect the wire harness from the travel module.
2 Remove the travel module E-clip and set aside.
3 Locate the 4 screws which hold the travel module and
plate to the motor and remove.
4 Discard the old travel module.
Installation
Model 041A7114-7 Model 041D8071-4
1 Disconnect the wire harness from the
travel module.
2 Locate the 2 screws which hold the
travel module to the motor and remove.
3 Discard the old travel module.
Wire Harness
3 Remove the old travel module
E-clip
Screws
Wire Harness
Screws
