Chamberlain B500 - Page 43

43
Repair Parts
Rail Assembly Parts
Accessories
Installation Parts
1
3
2
4
6
5
1
2
3
Description Part Number
1 Belt 041A5250
2 Pulley 144C54
3 Master Link 4A1008
4 Rail 041A5665
5 Trolley Assembly 041C5141-2
6 “U” Bracket 041D0598
Not Shown
Wear Pads 183A163
Hardware Bag 041A7920-2
Description Part Number
1 Multi-Function Control
Panel
041A7185-1
2 3-Button Remote
Control Models B503
and B510
953ESTD
3 1-Button Remote
Control Model B500
950ESTD
Description Part Number
1 Curved Door Arm 178B35
2 Door Bracket with Clevis
Pin and Fastener
41A5047-1
3 Emergency Release Rope
and Handle
41A2828
4 Header Bracket with Clevis
Pin and Fastener
41A5047-2
5 Remote Control
Visor Clip
29B137
6 Safety Sensor Bracket 041A5266-3
7 Safety Sensor Kit Receiving
and sending sensors with
wire
41A5034
8 Straight Door Arm 178B34
9 White and Red/White Wire 41B4494-1
10 3V CR2030 Lithium Battery 10A20
11 Hanging Brackets 12B776
Not Shown
Owner’s Manual 114A5009
