Chamberlain Contractor Series - Verify Door Control Wiring Correctness

28
Power
3 Ensure the Door Control is Wired Correctly
Models: 8155W, 8160W, 8160WB, 8165W
If the door control has been installed and wired correctly, the command LED behind the
push bar will blink.
COMMAND LED
Push bar
RED
WHITE
WHITE
GREY
Models: 8164W
If the door control has been installed and wired correctly, the LED behind the push
button will blink (883LMW).
883LMW
RED
WHITE
WHITE
GREY
Push
Button
