51
Repair Parts
1
2
3
10
12
13
14
8
7
6
4
5
11
9
Description Part Number
1 Sprocket cover 041A4371
2 Gear and sprocket 041A4885-4
3
Drive and Worm Gear 041A2817
4 Front end panel with all labels 041A8393
5 Light socket 041C0279
6 Light lens K108D0079M
7 Capacitor 030B0532-1
8 Capacitor bracket K012A0373
9 Universal motor 041D7440
10 Travel module 041D7742-7
11 Cover 041D9018
12 Logic board 050ACTWF
13 Logic board end panel 041D0239-1
14 Line Cord 041B4245-1
Not Shown
Wire Harness 041A7946
Terminal Block 041A3150
Garage Door Opener Parts
Model 8155W
