Factory
Setting
Description of Task Programming Procedure
Programming
Number
86
Verify a Card
85
Replace a Card
88
Delete a Card
90
Add a Basic Transmitter
90 # (transmitter PIN code) # (facility code) #
(sequence number) # (ID number) # (button number) #
87
Activate or Deactivate a Card
91
Add or Edit a Full Function Transmitter
Configure “Door Held Open” Alarm
Feature
102 # (alarm option; 0 = disable, 1 = enable until
relay time expires, 2 = enable until alarm clears) #
(relay group, 0000-1111) #
Order of relays is 4321
Configure “Door Forced Open” Alarm
Feature
103 # (alarm option; 0 = disable, 1 = enable until
relay time expires, 2 = enable until alarm clears) #
(relay group, 0000-1111) #
Order of relays is 4321
96
Verify a Transmitter
96 # (transmitter PIN code) # (facility code) #
(sequence number) # (ID number) # (button number) #
94
Add a Group of Transmitters at Once
95 # (transmitter PIN to change) # (facility code) #
(sequence number) # (ID number) # (button number)
# (new transmitter PIN) # (new facility code) # (new
sequence number) # (new ID number) # (new button
number) #
95
Replace a Lost Transmitter
100
102
103
Deactivate a Button on a Transmitter
and/or Delete a Transmitter
100 # (transmitter PIN code) # (facility code) #
(sequence number) # (ID number) # (button number) #
98
Activate or Deactivate a Transmitter
Disabled
Disabled
Optional Steps Indicated with a Background, all other steps are Required
85 # (lost or stolen card PIN code) # (facility code) #
(card type, 26 or 30) # (new card PIN) # (new facility
code) # (new card type, 26 or 30) #
86 # (card PIN code) # (facility code) # (card type, 26
or 30)
87 # (card PIN code) # (facility code) # (card type, 26
or 30) # (0 = deactivate; 1 = activate) # (0 = don't use
start; 1 = use start) # (Start Date = yymmdd) # (Start
Time = hhmm) # (0 = don't use end; 1 = use end) #
(End Date = yymmdd) # (End Time = hhmm) #
88 # (card PIN code) # (facility code) # (card type, 26
or 30) #
91 # (transmitter PIN code) # (facility code) #
(sequence number) # (ID number) # (button number)
# (schedule for door 1, 0-63) # (schedule for door 2,
0-63) # (schedule for door 3, 0-63) # (schedule for
door 4, 0-63) #
94 # (transmitter PIN code start range) # (transmitter
PIN code end range) # (facility code) # (sequence
number) # (ID number) # (button number) #
(0 = deactivate; 1 activate) # (schedule for door 1,
0-63) # (schedule for door 2, 0-63) # (schedule for
door 3, 0-63) # (schedule for door 4, 0-63) #
98 # (transmitter PIN code) # (facility code) #
(sequence number) # (ID number) # (button number)
# (0 = deactivate; 1 activate) # (0 = don't use start; 1 =
use start) #(Start Date = yymmdd) # (Start Time =
hhmm) # (0 = don't use end; 1 = use end) #(End Date
= yymmdd) # (End Time = hhmm) #
