7
Operator Specifications
Usage Classification
Class I & II
Main AC Supply
120 Vac, .5 Amps (6.5 Amps including Accessory Outlets)
System Operating Voltage
12 Vdc Battery Run / Battery Backup
Accessory Power
12 Vdc, 500mA max. for ON + SW (switched)
Solar Power Max
12 Vdc at 30 watts max.
Maximum Gate Weight
800 lbs (363.6 kg)
Minimum Gate Travel Distance
25 feet (7.62 m)
Maximum Gate Travel Distance
50 feet (15.24 m)
Maximum Gate Travel Speed
12 inches/second
Maximum Daily Cycle Rate
120 cycles/day
Maximum Duty Cycle
Continuous
Operating Temperature
Without Heater: -20°C to 60°C (-4°F to 140°F)
With Optional Heater: -40°C to 60°C (-40°F to 140°F)
Expansion Board
Optional
External Entrapment Protection Device Inputs (non-contact
and/or contact)
Main board - up to 2 close entrapment protection devices and 1 open entrapment
protection device.
Expansion board - up to 3 entrapment protection devices configurable to either close or
open and up to 4 edge sensors using wireless edge sensor kit model LMWEKITU .
INTRODUCTION
