USER’S GUIDE

VEHICULAR SLIDE/SWING GATE OPERATORS

Your model may look different than the model illustrated in this user’s guide.

CSL24V ™ & CSL24VH ™

CSW24V ™ & CSW24VH ™

Installation Date

www.liftmaster.com

Please contact your authorized LiftMaster dealer

for all of your service needs.

Table of Contents

Other manuals for Chamberlain LiftMaster CSL24V

Installation Manual48 pages

Quick Start Guide2 pages

Questions and Answers:

T
Timothy AlvarezJul 29, 2025
How to fix Chamberlain LiftMaster CSL24V that doesn't fully open or close when setting limits?
- S
  samanthabakerJul 29, 2025
  If your Chamberlain Gate Opener doesn't fully open or close when setting the limits, check the DIAGNOSTIC LEDs. Also, check the chain, use the manual disconnect to move the gate manually, and ensure the gate moves easily from limit to limit, repairing the gate as needed. If the gate is too difficult to move, repair it as needed. The gate must move easily and freely through its entire range, limit-to-limit; repair the gate as needed.
R
richardhoAug 2, 2025
What to do if my Chamberlain LiftMaster CSL24V Gate Opener moves but I cannot set the correct limits?
- A
  Ashley OrozcoAug 2, 2025
  If your Chamberlain Gate Opener moves, but you can't set the correct limits, check the DIAGNOSTIC LEDs and the Open and Close command input LEDs. Ensure that the stop button is not active and that the reset switch is not set to RESET. If operating on battery power, ensure the batteries are adequately charged. Also, verify that the Entrapment Protection Device and any vehicle loop detectors or probes are not active. If problems persist, the control board may be defective and require replacement.
W
Wanda MerrittAug 6, 2025
How to troubleshoot a Chamberlain LiftMaster CSL24V that doesn't run and the diagnostic LED is off?
- A
  Andrew DiazAug 6, 2025
  If your Chamberlain Gate Opener isn't running and the diagnostic LED is off, it indicates a power issue. First, check both the AC and battery power. Next, inspect the fuses. If it's running on battery power only, the batteries might be low or dead; try charging them via AC or solar power, or replace them. If none of these steps work, the control board might be defective and need replacement.
R
Robert WilcoxAug 11, 2025
Why doesn't my Chamberlain LiftMaster CSL24V stop and reverse when there's an obstruction?
- J
  Jon DanielsAug 11, 2025
  If your Chamberlain Gate Opener doesn't stop and reverse when something is in its path, the force setting might be too high. Try adjusting the force setting and then retest to ensure the gate stops and reverses when it encounters an obstruction.
V
vwyattAug 15, 2025
What to do if my Chamberlain LiftMaster CSL24V control board powers up, but the motor doesn't run?
- A
  Angela FarrellAug 15, 2025
  If the control board of your Chamberlain Gate Opener powers up but the motor doesn't run, several issues could be the cause. Here's what to check: * Check the DIAGNOSTIC LEDs. * Ensure the reset switch is not set to RESET. * Make sure the stop button is not active. * If using battery power, ensure the batteries are not low or dead; charge or replace them if needed. * Check the Open and Close command input LEDs. * Verify that the Entrapment Protection Device is not active. * Confirm that the vehicle loop detector or probe is not active. * If none of these resolve the issue, the control board might be defective and need replacement.
M
matthew72Aug 19, 2025
What to do if my Chamberlain LiftMaster CSL24V Gate Opener relay clicks but the motor won't turn on?
- T
  Tammy BlackAug 19, 2025
  If the relay clicks when you send a command but the motor of your Chamberlain Gate Opener doesn't turn on, it could be due to a few reasons: * The chain might be jammed. Check the chain, manually disconnect the gate, and ensure it moves easily. Repair the gate if needed. * There might be a defect in the motor or motor wires. Inspect them for any damage, open wires, or shorts. Replace the motor if necessary. * The control board could be defective and require replacement.
C
Charles JimenezAug 23, 2025
Why won't my Chamberlain LiftMaster CSL24V respond to wired controls?
- R
  Rebecca MartinAug 23, 2025
  If your Chamberlain Gate Opener isn't responding to a wired control, check the DIAGNOSTIC LEDs. Also, check the XMITTER LED when a wireless control is activated. Ensure that the stop button is not active and that the reset switch is not set to RESET. If using a wireless control, poor radio reception could be the issue; check if a similar wired control operates correctly. If none of these steps work, the control board may be defective and need to be replaced.

Chamberlain LiftMaster CSL24V Specifications

General

Brand	Chamberlain
Model	LiftMaster CSL24V
Category	Gate Opener
Language	English

Summary

Gate Operator Operation

Reset Switch and Manual Disconnect

Explains the reset switch function for stopping, disabling, and manually operating the gate.

CSL24V Slide Gate Operator Manual Disconnect

Instructions on using the reset switch to manually operate the CSL24V slide gate.

CSW24V Swing Gate Operator Manual Disconnect

Instructions for manually operating the CSW24V swing gate using the reset switch and handle.

Operator Alarm and Reset

Details on operator alarms triggered by obstructions and the reset procedure.

Remote Control Operation

Explains how to use the remote control for opening, stopping, and closing the gate.

Gate Operator Maintenance

Monthly Maintenance Checks

Tasks for monthly checks including entrapment devices, warning signs, and gate inspection.

Periodic Maintenance by Dealer

Defines tasks to be checked every 6 months and 3 years by an authorized dealer.

Battery Maintenance and Replacement

Guidance on battery degradation, replacement every 3 years, and proper disposal.

Drive Chain Adjustment (Slide Only)

Instructions on tightening the drive chain on slide gate operators.

Gate Operator Accessories

Entrapment Protection Devices

Details on photoelectric sensors and sensing edges for obstacle detection.

Remote Controls

Information on various LiftMaster remote controls like 3-button and mini-remote models.

Keyless Entry

Description of the 4-digit code keypad for gate operation.

Additional Gate Operator Accessories

Miscellaneous Accessories

Includes post-mounting plates, remote antenna extension kits, and wireless receivers.

Heater Options

Details on heaters for maintaining operator temperature in cold conditions.

Loop Detectors

Information on low power loop detectors and plug-in loop detectors.

Gate Access System Components

Vehicle Sensing Probe

Describes a probe buried in the ground to detect vehicles and open the gate.

Solar Panel Kit

Details on a 10-watt solar panel kit for powering the operator.

Gate Access System Batteries

Information on battery replacement, types (7AH, 33AH), and battery trays.

Gate Locks

Description of solenoid and magnetic gate locks for securing the gate.
