Champ FX390 - Crankcase

Crankcase
20
Ref # Part # Description Qty
1 CH78222 CRANKCASE SUBASSEBMLY 1
2 CH78223 OIL SEAL 1
3 CH78224 WASHER 2
4 CH78225 BOLT 2
5 CH78226 OIL SENSOR 1
6 CH78227 BOLT 1
7 CH78228 BEARING 1
8 FX390-007 OIL LEVEL ASSEMBLY 1
9 CH78231 BOLT 2
10 CH78232 WASHER 1
11 CH78233 GOVERNOR ARM 1
12 CH78234 SEAL 1
13 CH78235 PIN 1
