SPECIFICATION
MODEL FX390,FX390E
Bore x Stroke (MM) 88X64
Displacement (CC) 389
Compression Ratio 8.5:1
Net Power (Kw/Rpm) 7.8/3600
Net Torque (N.m/Rpm) 25/2500
PTO shaft rotation Counter Clock wise
Ignition system Transistorized magneto ignition
Lubrication system Forced splash
Carburetor Flat suction valve carburetor
Governor system Centrifugal mechanical
Engine Type Forced air-cooling 4 stroke, OHV
Starting system Recoil/Electric start
Fuel Tank Capacity (L) 6.5
Engine Oil Capacity (L) 1.1
Fuel Consumption (g/Kw.h) ≤374
Dimension (LxWxH MM) 465x415x440
Net Weight (Kg) 30.5/33.5
