Operation
Operation Sequence (continued)
1 MIN CYCLE
WASH TEMP
150
WASHING
89
TIME REMAINING
Touch to Change
1 MIN CYCLE
RINSE TEMP
185
RINSING
49
TIME REMAINING
Touch to Change
7 8
When 1 MIN CYCLE is selected, the machine
starts and the WASHING time remaining
counter is displayed.
At the end of the wash cycle the 15 sec.
final rinse begins. The RINSE TEMP displays
must be between 185-195°F.
1 MIN CYCLE
WASH TEMP DWELLING
35
TIME REMAINING
Touch to Change
DWELLING is displayed as the
10 sec. DWELL begins.
9
1 MIN CYCLE
WASH TEMP RECOVERY
29
TIME REMAINING
Touch to Change
10
FOR VHR ONLY: RECOVERY is displayed
as the heat recovery fan removes steam
from the wash chamber.
1 MIN CYCLE
WASH TEMP
TIME REMAINING
Touch to Change
READY
11
The display returns to READY at the
end of the 1 MIN CYCLE. Open the
doors, and remove the rack of clean
wares.
NOTE:
The Standard Machine operation
sequence is identical to the VHR
except it does not have include
RECOVERY time.
4
