Champion M2 Series User Manual

Operation
Machine Assembly
Fig. 5
WASH SPRAY ARM
RINSE SPRAY ARM
PUMP STRAINER
Fig. 4
SCRAP SCREENS X 2
• Install the pump suction strainer.
• Install the scrap screens and screen spacer.
• Install the upper and lower wash and rinse spray arms. The arms are interchangeable.
• Make sure the arms spin freely.
To Assemble the dishwasher:
8
