Operation
Rinse Sentry
Rinse Sentry extends the wash cycle time 660 seconds so the final rinse booster tank temp-
erature has time to reach the minimum required final rinse water temperature of 180°F.
After 660 seconds, Rinse Sentry will stop and the cycle will resume unless the optional
LOW TEMP LOCKOUT feature is enabled.
The Rinse Sentry operation follows:
1 MIN CYCLE
WASH TEMP
150
WASHING
LOW TEMP
660
TIME REMAINING
Touch to Change
1 MIN CYCLE
WASH TEMP
150
WASHING
70
TIME REMAINING
Touch to Change
1 MIN CYCLE
WASH TEMP
150
WASHING
LOW TEMP
0
TIME REMAINING
Touch to Change
1
2
1
The booster LOW TEMP alarm appears
and 660 seconds begins to countdown in
the TIME REMAINING window.
The LOW TEMP alarm disappears
when the booster reaches temperature
and the normal cycle resumes.
The 660 second Rinse Sentry Time
Remaining countdowns to zero.
Low Temp Lockout Option
The low temp lockout option is set at the factory or in the field by a service technician.
It stops the machine if the rinse sentry alarm is activated for longer than 660 seconds.
Only an authorized service technician may reset the lockout.
The LOW TEMP LOCKOUT operation follows:
1-800-XXX-XXXX
WASH TEMP
150
CALL FOR
SERVICE
LOW TEMP
TIME REMAINING
Touch to Change
2
The machine locks out, a red LOW TEMP
alarm appears, CALL FOR SERVICE appears,
and a service number to call appears.
5
