Champion PORTABLE GENERATOR User Manual

Specifications
Rev 41152-20100413 E 19
Parts List
#
Part Number
Description
Qty.
1
29.001
Switch，flameout
1
2
5A122
Control panel
1
3
GB818 M3!6
Screw M3!6
4
4
ST02FD-05302001-L20(CSA)
20A Breaker
1
5
ST02FD-05602010-D
Voltage meter
1
6
ST02FD-05502020(CSA)
Receptacle L5-30R
1
7
ST02FD-05502022(CSA)
Receptacle L14-30R
1
8
ST02FD-05502023(CSA)
Receptacle 5-20R
1
ST02FD-05402004-RC
positive terminal(red)
1
9
ST02FD-05402004-BC
negative terminal(black)
1
10
GB5783 M6!22
Bolt M6x22
1
11
GB97.1 6
Washer"6
6
12
GB93 6
Locking washer"6
6
13
GB6175 M6
Nut M6
2
14
ST02FD-05302007-12(CSA)
D.C 12A Breaker
1
15
ST05FD-05205009.1
control box
1
16
ST05FD-05215002
plug
1
17
ST05FD-05215008
pipe（Metal）
1
18
ST05FD-05215004
plug
1
19
ST05FD-05215006
plug
1
20
GB818 M5!38
Screw M5!38
3
21
GB97.1 5
Washer "5
9
22
BG01-00000000
Rectifier
1
23
ST02FD-05302005-25（CSA）
250V 25A DOUBLE breaker
1
24
ST182FDE-1000000-G
G style Engine
1
25
ST05FD-1151600
fan cover
1
26
GB5789 M6!8
Flange Bolt M6!8
4
27
ST05FD-1152020-4(CSA)
Rotor assembly
1
28
GB96 10
Washer #10
1
29
GB7244 10
Locking washer #10
1
30
ST05FD-1152010-4(CSA)
Stator assembly
1
31
ST05FD-1152005-4
Flange bolt M10!1.25!250
1
32
ST05FD-1152003-4
Stator cover
1
33
ST05FD-1152004-4
Flange bolt M6!165
4
34
ST05FD-1152002
End housing
1
35
ST05FD-1152035
carbon brush assembly
1
36
ST02FD-02100008
pinch
1
37
ST05F-1152030(CSA)
AVR(CSA)
1
38
ST02FD-02100010
terminal block
1
39
GB16674 M5!16
Flange Bolt M5!16
6
40
ST05FD-1152001
Generator end cover
1
41
GB16674 M5!12
Flange Bolt M5!12
4
42
GB93 5
locking washer "5
8
43
ST188FD-1732100
Muffler inner cover
1
44
GB5789 M6!12
Flange Bolt M6!12
17
45
GB5789 M8!35
Flange Bolt M8!35
1
46
ST188FD-1730003
Bushing "8.5
1
47
GB5789 M8!20
Flange Bolt M8!20
1
48
ST188FD-1731000A
muffler
1
49
ST188FD-1732200-A
Muffler outer cover
1
50
ST188FD-1180121
Spark arrester
1
51
ST188FD-1100010-88
Spark arrester pinch
1

Champion PORTABLE GENERATOR Specifications

General

Engine Type	4-stroke OHV
Starting System	Recoil
AC Output	120V
DC Output	12V
Fuel Type	Gasoline
Outlets	12V DC
