Specifications
Rev 41152-20100413 E 17
Specifications
Engine Specifications
Engine 338 cc OHV CPE
Generator Specifications
Running Wattage 5500 Watts
Starting Wattage 6500Watts
AC Load 120/240 V
DC Load 12 V 8.3 A
Neutral bonded to frame
Phase Single
Frequency 60 Hz
Fuel Capacity 6.5 gallons (25 L)
Weight 197.3 lbs. (89.5 kg)
Height 25.2 inches (64 cm)
Width 26.6 inches (67.5 cm)
Length 27.7 inches (70.5 cm)
Fuel
Fuel capacity is 6.5 US gallons (25 L). Use
regular unleaded gasoline with a minimum
octane rating of 85.
Oil
Oil capacity is 1.16 qt (1.1 L).
Spark Plugs
Your generator comes equipped with a #”
(19 mm) long reach plug.
Intermittent use (less than 1 hour/month) or
colder temperatures (below 60°F)
NGK BPR6ES or equivalent
Moderate use (less than 3 hours/month) or
seasonal temperatures (50-80°F)
NGK BPR7ES or equivalent
Extreme use (continuous) or hot climates
(80-100°F)
NGK BPR8ES or equivalent
Make certain the spark plug gap is 0.7 -
0.8mm (0.028 - 0.031 in.).
Valve Clearance
Intake 0.13-0.17mm (0.005 – 0.007 in.)
Exhaust 0.18-0.22mm (0.007 – 0.009 in.)
