CHAMPIONX WELLMARK DigiMax - 115 VAC, 60 RPM Motor (General Purpose)

7
115VAC, 60 RPM Motor (General Purpose)
*Timer settings highlighted and in bold represent flow rates greater than the maximum recommended flow rate sizing (75% of max)
Pin 1 Pin 2 Pin 3 Pin 1 Pin 2 Pin 3 Pin 1 Pin 2 Pin 3
0.5 1 / 119 1 / 119 1 / 119 1 / 119
1.0 3 / 117 2 / 118 1 / 119 1 / 119 1 / 119 1 / 119 1 / 119
2.0 5 / 115 4 / 116 3 / 117 2 / 118 2 / 118 1 / 119 1 / 119 1 / 119 1 / 119
3.0 8 / 112 6 / 114 4 / 116 3 / 117 2 / 118 2 / 118 2 / 118 1 / 119 1 / 119
4.0 10 / 110 7 / 113 6 / 114 5 / 115 3 / 117 3 / 117 3 / 117 2 / 118 1 / 119
5.0 13 / 107 9 / 111 7 / 113 6 / 114 4 / 116 3 / 117 3 / 117 2 / 118 2 / 118
6.0 16 / 104 11 / 109 9 / 111 7 / 113 5 / 115 4 / 116 4 / 116 3 / 117 2 / 118
7.0 18 / 102 13 / 107 10 / 110 8 / 112 6 / 114 5 / 115 5 / 115 3 / 117 3 / 117
8.0 21 / 99 15 / 105 12 / 108 9 / 111 7 / 113 5 / 115 5 / 115 4 / 116 3 / 117
9.0 24 / 96 17 / 103 13 / 107 10 / 110 7 / 113 6 / 114 6 / 114 4 / 116 3 / 117
10.0 26 / 94 19 / 101 15 / 105 12 / 108 8 / 112 6 / 114 7 / 113 5 / 115 4 / 116
12.0 31 / 89 22 / 98 17 / 103 14 / 106 10 / 110 8 / 112 8 / 112 6 / 114 4 / 116
14.0 37 / 83 26 / 94 20 / 100 16 / 104 12 / 108 9 / 111 9 / 111 7 / 113 5 / 115
16.0 42 / 78 30 / 90 23 / 97 19 / 101 13 / 107 10 / 110 10 / 110 7 / 113 6 / 114
18.0 47 / 73 34 / 86 26 / 94 21 / 99 15 / 105 12 / 108 12 / 108 8 / 112 7 / 113
20.0 52 / 68 37 / 83 29 / 91 23 / 97 17 / 103 13 / 107 13 / 107 9 / 111 7 / 113
25.0 65 / 55 47 / 73 36 / 84 29 / 91 21 / 99 16 / 104 16 / 104 12 / 108 9 / 111
30.0 79 / 41 56 / 64 44 / 76 35 / 85 25 / 95 19 / 101 20 / 100 14 / 106 11 / 109
35.0 92 / 28 65 / 55 51 / 69 41 / 79 29 / 91 23 / 97 23 / 97 16 / 104 13 / 107
40.0 105 / 15 75 / 45 58 / 62 47 / 73 33 / 87 26 / 94 26 / 94 19 / 101 15 / 105
45.0 118 / 2 84 / 36 65 / 55 52 / 68 37 / 83 29 / 91 29 / 91 21 / 99 16 / 104
50.0 93 / 27 73 / 47 58 / 62 42 / 78 32 / 88 33 / 87 23 / 97 18 / 102
60.0 112 / 8 87 / 33 70 / 50 50 / 70 39 / 81 39 / 81 28 / 92 22 / 98
70.0 102 / 18 82 / 38 58 / 62 45 / 75 46 / 74 33 / 87 25 / 95
80.0 116 / 4 93 / 27 67 / 53 52 / 68 52 / 68 37 / 83 29 / 91
90.0 105 / 15 75 / 45 58 / 62 59 / 61 42 / 78 33 / 87
100.0 116 / 4 83 / 37 65 / 55 65 / 55 47 / 73 36 / 84
125.0 104 / 16 81 / 39 82 / 38 58 / 62 45 / 75
150.0 97 / 23 98 / 22 70 / 50 55 / 65
175.0 113 / 7 115 / 5 82 / 38 64 / 56
200.0 94 / 26 73 / 47
225.0 105 / 15 82 / 38
250.0 117 / 3 91 / 29
300.0 109 / 11
Qts/Day
Target
1/4" Plunger
3/8" Plunger
1/2" Plunger
