11 Ref. : CH - 1249 - A - 2
Top insulation blanket
Bottom insulation blanket
Insulation positioning
Fig. 10
Stud M 10 x 90
Hinge
Stud M 10 x 90
Stud M 10 x 90
Stud M 10 x 90
Screw TH M 10 x 30
Screw TH M 10 x 30
Screw TH M 10 x 30
Screw TH M 10 x 30
Hinge
Hinge
Hinge
Guide
Guide
Door hinge and door guide
assembly
Pre-drilled
burner door
Fig. 11
Fig. 12
Screw TH M 10 x 30
Stud M 10 x 90
Stud M 10 x 90
Screw TH M 10 x 30
Stud M 10 x 90
Stud M 10 x 90
4 holes M 8 equidistant on a perforation Ø of 170
4 holes M 10 equidistant on a perforation Ø of 200
4 holes M 14 equidistant on a perforation Ø of 254
Side insulation
blanket
Rear insulation
blanket
N0226400.PLT
N0225600.PLT
N02187-01.DSF
Front insulation blanket
Front
