Char-Broil 463341021 - Warranty Part Replacement Guide - LED Wire Harness; Door Assembly Replacement; LED Wire Connection and Disconnection

PAGE 2
1
2
Disconnect / connect LED WIRE from battery box and LED switch.
Each step shows removal and replacement of parts. Follow the steps in order to remove parts, then reverse the
steps to replace all parts.
Remove / replace DOOR ASSEMBLY.
1ST
2ND
PRESS
LED WIRE
LED WIRE
