Char-Broil 463349917 - User Manual

Questions and Answers

K
Kimberly DavisAug 15, 2025
Why is there a sudden drop in gas flow in my Char-Broil Grill?
- C
  Charles SmithAug 15, 2025
  A sudden drop in gas flow or low flame in your Char-Broil Grill can be caused by several factors. First, check if you are out of gas in the LP cylinder. If not, the excess flow valve may have tripped; in this case, turn off the knobs, wait 30 seconds, and light the grill. If flames are still low, turn off the knobs and LP cylinder valve, disconnect the regulator, reconnect it, perform a leak test, turn on the LP cylinder valve, wait 30 seconds, and then light the grill. Another potential cause is a vapor lock at the coupling nut/LP cylinder connection; turn off the knobs and LP cylinder valve, disconnect the coupling nut from the cylinder, reconnect it, and try again.
M
Mackenzie StephensonAug 18, 2025
What to do if the flames blow out on my Char-Broil Grill?
- M
  Mary CombsAug 18, 2025
  If the flames on your Char-Broil Grill blow out, it could be due to high or gusting winds. Try turning the front of the grill to face the wind or increase the flame height by turning the gas valve to a higher position. It could also be because you are low on LP gas, so refill the LP cylinder. Finally, the excess flow valve might have tripped. Refer to the "Sudden drop in gas flow" instructions to resolve this.
T
Taylor HernandezAug 21, 2025
Why won't one burner light from other burners on my Char-Broil Grill?
- J
  Joseph CrosbyAug 21, 2025
  If one burner does not light from the other burners on your Char-Broil Grill, it's likely due to grease buildup or food particles in the end(s) of the carryover tube(s). Clean the carry-over tube(s) with a wire brush to resolve this issue.
A
Austin HooverAug 25, 2025
What to do if no sparks appear at any electrodes when Electronic Ignition Button is pressed on my Char-Broil Grill, but noise can be heard from spark module?
- D
  Donald OliverAug 26, 2025
  If no sparks appear at any electrodes when the Electronic Ignition Button is pressed on your Char-Broil Grill, but noise can be heard from the spark module, the output lead connections may not be connected. Remove and reconnect all output connections at the module and electrodes.
C
coledeniseAug 28, 2025
What to do if sparks are present but not at all electrodes and/or not at full strength on my Char-Broil Grill?
- J
  Jose MccoyAug 28, 2025
  If sparks are present but not at all electrodes and/or not at full strength on your Char-Broil Grill, check the following: * Ensure output lead connections are connected by removing and reconnecting all output connections at the module and electrodes. * Look for arcing to the grill away from the burner(s), observing the grill in a dark location while operating the ignition system to check for arcing between output wires and the grill frame. * Replace the battery with a new alkaline battery if it is weak. * Remove moisture from the electrodes with a paper towel if they are wet. * Replace cracked or broken electrodes if they are damaged.
D
Daniel AdkinsSep 1, 2025
What to do if I have a flare-up on my Char-Broil Grill?
- B
  Brett LandrySep 1, 2025
  Flare-ups on your Char-Broil Grill can occur due to grease buildup, excessive fat in the meat, or excessive cooking temperature. To resolve this, clean the burners and the inside of the grill/firebox. Also, trim fat from the meat before grilling. Finally, adjust the cooking temperature accordingly by lowering it.
B
Barbara FarleySep 4, 2025
What to do if I have a persistent grease fire in my Char-Broil Grill?
- R
  rfreemanSep 4, 2025
  If you experience a persistent grease fire in your Char-Broil Grill, it's likely due to grease trapped by food buildup around the burner system. Turn the knobs to OFF and turn the gas off at the LP cylinder. Leave the lid in position and let the fire burn out. After the grill cools, remove and clean all parts.
A
April JonesSep 7, 2025
How to fix a flashback (fire in burner tube(s)) in Char-Broil Grill?
- D
  Dylan ElliottSep 7, 2025
  A flashback, or fire in the burner tubes, in your Char-Broil Grill, is usually caused by blocked burner and/or burner tubes. Turn the knobs to OFF and clean the burner and/or burner tubes.
A
Anna MarshallSep 12, 2025
What to do if no sparks appear at any electrodes when Electronic Ignition Button is pressed and no noise can be heard from spark module on my Char-Broil Grill?
- A
  Abigail WalkerSep 12, 2025
  If no sparks appear at any electrodes when the Electronic Ignition Button is pressed and no noise can be heard from the spark module on your Char-Broil Grill, check the following: 1. Ensure the battery is installed properly, making sure that “+” and “–” connectors are oriented correctly, with “+” on the cap end. 2. Replace the battery with a new alkaline battery if the current one is dead. 3. Unscrew and reinstall the button cap assembly, ensuring the threads are aligned and engaged fully. 4. Replace the spark module assembly if it is faulty.

Summary

Safety Precautions and Warnings

General Grill Safety

Essential safety guidelines for operating the grill safely.

Grease Fire Management

Procedures for preventing and handling grease fires.

Installation and LP Cylinder Safety

Installation Safety Precautions

Critical safety guidelines for setting up the grill.

LP Cylinder Handling and Leak Testing

Safe procedures for connecting, testing, and handling the LP cylinder.

Component Safety Checks

Steps for leak testing valves, hoses, and regulators.

Grill Operation and Maintenance

Safe Grill Usage and Ignition

Instructions for safe operation, ignition, and lighting procedures.

Component Checks and Storage

Guidelines for checking components, turning off the grill, and proper storage.

Grill Cleaning and Burner Assembly

Spider Alert and Venturi Cleaning

Warning about spider blockages and cleaning venturi tubes.

General Grill Cleaning Procedures

Instructions for cleaning various grill surfaces and components.

Burner Assembly Cleaning

Detailed steps for cleaning and maintaining the burner assembly.

Grill Assembly Instructions

Cart and Frame Assembly

Assembling the main grill cart, frame, and base components.

Side Shelf and Panel Installation

Attaching side shelves, front/rear panels, and fascias.

Burner, Lid, and Door Installation

Installing burners, lid, grates, ignitor, grease tray, and doors.

Grilling Guide and Techniques

Getting Started and First-Time Use

Initial setup, preparation, and first-time operation of the grill.

Cooking Methods and Food Safety

Explanations of cooking techniques and critical food safety practices.

Grilling Tips and Tricks

Advice on sauces, marinades, wood chips, skewers, and utensils.

Troubleshooting and Emergency Procedures

Emergency Procedures and Gas Issues

Actions for gas leaks, fires, and common gas-related problems.

Electronic Ignition Troubleshooting

Detailed steps for diagnosing and fixing electronic ignition issues.

Parts and Hardware Reference

Parts Diagram and Lists

Illustrated parts diagram, parts list, and hardware list for reference.

Warranty and Product Registration

Limited Warranty Information

Details of the manufacturer's limited warranty coverage and terms.

Product Registration Options

Instructions and options for registering the grill for warranty purposes.

Char-Broil 463349917 Specifications

General

Brand	Char-Broil
Model	463349917
Type	Gas Grill
Fuel Type	Liquid Propane
Burners	4
Main Burner BTUs	36, 000
Side Burner BTUs	10, 000
Burner Material	Stainless Steel
Material	Steel
Ignition	Electronic
