Char-Broil 463347017 - User Manual

Questions and Answers

T
Tim SmithAug 15, 2025
What to do if the flames blow out on my Char-Broil Grill?
- E
  Erin MasseyAug 15, 2025
  If the flames are blowing out on your Char-Broil Grill, it could be due to high or gusting winds. Try turning the front of the grill to face the wind or increase the flame height by turning the gas valve to a higher position. Another cause could be low LP gas, so refill the LP cylinder. It's also possible that the excess flow valve has tripped; in this case, refer to “Sudden drop in gas flow”.
M
Michael SchmidtAug 18, 2025
Why is there a sudden drop in gas flow on my Char-Broil 463347017?
- Q
  qdavisAug 18, 2025
  A sudden drop in gas flow or low flame on your Char-Broil Grill can happen if you're out of gas, so check the LP cylinder. Another cause could be a tripped excess flow valve. To fix this, turn off the knobs, wait 30 seconds, and light the grill. If the flames are still low, turn off the knobs and LP cylinder valve, disconnect the regulator, reconnect it, leak-test, turn on the LP cylinder valve, wait 30 seconds, and then light the grill. Vapor lock at the coupling nut/LP cylinder connection can also cause this issue. Turn off the knobs and LP cylinder valve, disconnect the coupling nut from the cylinder, reconnect it, and try again.
P
Patrick SuttonAug 21, 2025
Why doesn't one burner light from the others on my Char-Broil 463347017?
- D
  Derek SchultzAug 21, 2025
  If one burner does not light from the other burners on your Char-Broil Grill, it might be due to grease buildup or food particles in the end(s) of the carryover tube(s). Clean the carry-over tube(s) with a wire brush to resolve this issue.
C
Courtney HumphreyAug 25, 2025
Why no sparks with noise from module on my Char-Broil 463347017?
- M
  Michael LiAug 26, 2025
  If no sparks appear at any electrodes when the Electronic Ignition Button is pressed on your Char-Broil Grill, but you can hear noise from the spark module, the output lead connections may not be connected. Remove and reconnect all output connections at the module and electrodes.
J
Jennifer GarnerAug 28, 2025
Why no sparks and no noise from module on my Char-Broil Grill?
- M
  Marcus GonzalezAug 28, 2025
  If no sparks appear at any electrodes when you press the Electronic Ignition Button on your Char-Broil Grill, and you hear no noise from the spark module, several issues could be at play. First, ensure the battery is installed correctly, with the “+” and “–” connectors oriented correctly, with “+” on the cap end. A dead battery could also be the culprit, so replace it with a new alkaline battery. Check that the button assembly is installed properly by unscrewing the button cap assembly and reinstalling it, making sure the threads are aligned and engaged fully. Finally, a faulty spark module could be the cause, in which case you should replace the spark module assembly.
A
Adrian TurnerSep 1, 2025
How to prevent flare-ups on my Char-Broil Grill?
- J
  Joan DanielsSep 1, 2025
  Flare-ups on your Char-Broil Grill are often caused by grease buildup. Make sure to clean the burners and the inside of the grill/firebox regularly. Also, excessive fat in the meat can cause flare-ups, so trim the fat before grilling. Finally, high cooking temperatures can lead to flare-ups, so adjust the temperature accordingly.
R
Ryan ChavezSep 3, 2025
What to do if I have a persistent grease fire on my Char-Broil 463347017?
- A
  Ashley MillerSep 4, 2025
  If you're experiencing a persistent grease fire on your Char-Broil Grill, it's likely due to grease trapped by food buildup around the burner system. Turn the knobs to OFF, turn the gas off at the LP cylinder, leave the lid in position, and let the fire burn out. After the grill cools, remove and clean all parts.
N
nicholastaylorSep 7, 2025
What causes flashback in the burner tubes of my Char-Broil 463347017?
- M
  Michael ObrienSep 7, 2025
  If you observe flashback (fire in burner tubes) in your Char-Broil Grill, it's likely that the burner and/or burner tubes are blocked. Turn the knobs to OFF and clean the burner and/or burner tubes. Refer to the burner cleaning section of the Use and Care guide for detailed instructions.
R
Richard PetersSep 12, 2025
Why are sparks weak on my Char-Broil Grill?
- A
  anorrisSep 12, 2025
  If sparks are present but not at all electrodes or not at full strength on your Char-Broil Grill, check the output lead connections and reconnect all output connections at the module and electrodes. Arcing to the grill away from the burner(s) can also be the cause. If possible, observe the grill in a dark location, operate the ignition system, and look for arcing between the output wires and the grill frame. A weak battery can cause this issue, so replace the battery with a new alkaline battery. Wet electrodes can also be a factor; use a paper towel to remove moisture. Finally, cracked or broken electrodes can cause sparks at the crack, so replace them if necessary.

Summary

Safety Symbol Explanations

Caution Symbol

Defines CAUTION as a potentially hazardous situation or unsafe practice, possibly resulting in minor or moderate injury.

Warning Symbol

Defines WARNING as a potentially hazardous situation that could result in death or serious injury if not avoided.

Danger Symbol

Defines DANGER as an imminently hazardous situation that will result in death or serious injury if not avoided.

Grease Fire Safety

Preventing and Extinguishing Grease Fires

Provides guidance on preventing grease fires and what to do if one occurs, including not using water.

California Proposition 65 Warnings

Installation Safety Precautions

Use and Care

LP Cylinder Removal, Transport, and Storage

Guidance on safely removing, transporting, and storing LP cylinders.

LP Cylinder Requirements

Details specifications for LP cylinders, including size, construction, and valve type.

LP Gas Properties and Filling

Explains LP gas characteristics and safe cylinder filling procedures.

LP Cylinder Exchange

Information on using exchange services for LP cylinders and ensuring compatibility.

LP Cylinder Leak Test

Step-by-step guide to performing a leak test on LP cylinders and connections.

Connecting Regulator to LP Cylinder

Leak Testing Valves, Hose, and Regulator

General Safety Tips

Grill Lighting Procedures

Electronic Ignitor Lighting

Step-by-step guide for lighting the grill using the electronic ignitor.

Match Lighting Procedure

Instructions for lighting the grill using a match and match holder.

Sideburner Lighting Procedures

Sideburner Ignitor Lighting

Guide for lighting the sideburner using the electronic ignitor.

Sideburner Match Lighting

Instructions for lighting the sideburner with a match.

Grill Operation and Maintenance

Burner Flame Check

Procedure to verify burner flame quality and consistency.

Component Checks and Grill Storage

Covers checks for ignitor, valve, hose integrity, and guidance on proper grill storage.

Turning Grill Off

Instructions for safely turning off the grill after use.

Venturi Tube Maintenance

General Grill Cleaning

Cleaning Different Grill Surfaces

Covers cleaning methods for plastic, porcelain, painted, and stainless steel surfaces.

Cooking Surface Cleaning

Guidance on cleaning grill cooking surfaces, emphasizing bristle brush safety.

Cleaning the Burner Assembly

Limited Warranty Information

Warranty Scope and Duration

Outlines what parts are covered, the warranty period, and type of failure covered.

Exclusions and Limitations

Details items not covered by the warranty and disclaimers of implied warranties.

Grilling Guide: Getting Started

Initial Grill Setup and Pre-Heating

Covers initial setup, first-time use, and pre-heating the grill for optimal performance.

Fuel and Temperature Gauge

Discusses the use of lava rocks/briquettes and the function of the temperature gauge.

Regulator Safety Device Reset

Procedure to reset the gas regulator safety device if the grill does not reach sufficient temperature.

Direct Cooking Method

Indirect Cooking Method

Rotisserie Cooking Method

Food Safety Guidelines

Internal Meat Temperatures

Grilling Guide: Tips & Tricks

Sauce and Marinade Application

Advice on applying sauces and marinades to enhance grilled food flavor and prevent burning.

Wood Chips and Skewers

Tips for using wood chips for smoke flavor and selecting appropriate skewers for grilling.

Grilling Utensils

Recommends using tongs or spatulas instead of forks for better grilling results.

Grilling Guide: Cleaning Your Grill

Importance of Grill Cleaning

Explains the necessity of regular grill cleaning to prevent fires and maintain performance.

Routine and General Cleaning

Covers daily cleaning after use and general cleaning of different grill parts.

Grill Storage and Critter Prevention

Guidance on proper grill storage and preventing critter blockages in venturi tubes.

Emergency Procedures

Gas Leak and Fire Emergencies

Actions for gas leaks and fires, including contacting emergency services and initial responses.

Troubleshooting Common Problems

Burner Ignition Troubleshooting

Steps to resolve issues with ignitor or match lighting for burners.

Flame and Gas Flow Issues

Addresses issues like low flame, blown-out flames, flare-ups, and flashbacks.

Electronic Ignition Troubleshooting

Detailed steps for electronic ignition system failures, covering spark module, wiring, and battery issues.

Char-Broil 463347017 Specifications

General

Type	Gas Grill
Brand	Char-Broil
Model	463347017
Category	Grill
Fuel Type	Propane
Material	Stainless Steel
Burner Material	Stainless Steel
Ignition Type	Push Button
Side Burner BTUs	10, 000 BTUs
Ignition System	Electronic Ignition
Cooking Area	650 sq. in.
