Char-Broil 500X - Hardware List and Safety Reminders; Detailed Hardware Inventory; General Hot Surface Warning

Flat-Head
Qty: 4
#10-24x1/2”
Machine Screw
Qty: 6
Qty: 2
Qty: 2
Qty: 2
Qty: 6 Qty: 14 Qty: 4 Qty: 2 Qty: 2
Hardware is shown actual size. You may have spare hardware after assembly is complete.
HARDWARE LIST
Insulated Washer 1/4-20 Flange Nut #10-24 Flange Nut #10-24 Hex Nut Vent Spring
Handle SpacerVent Knob
Logo Plate Clip
Small Cotter Pin
1/4-20x2 ½”
Machine Screw
Qty: 6
Machine Screw
Qty: 8
1/4-20 x 2”
Hinge Pin
Qty: 2
Page 7
WARNING
MOST SURFACES ON THIS UNIT ARE HOT WHEN IN USE.
USE EXTREME CAUTION. KEEP OTHERS AWAY FROM UNIT.
ALWAYS WEAR PROTECTIVE CLOTHING TO PREVENT INJURY.
