Char-Broil Performance T-47D User Manual

B
A
Tank exclusion wire shelf
Left side panel
Inside of cart, insert tank exclusion wire shelf ends into lower back panel, shown A.
Attach front left side of wire shelf to the left side panel with one #8-32x3/8” screw. Attach leg to bottom shelf with
one #8-32x3/8”screw, shown B.
14
#8-32x3/8"
screw
#8-32x3/8"
screw
22
