Step 10
Secure the Hose Guide Bracket to the side of the Grill. First unscrew the lower bolt
that secure the front side of the leg brace. Then place the Hose Guide over the Leg
Brace and re-screw the bolt.
Hose Guide Bracket
Lock Washer
Hex Bolt
Step 11
Install Side Shelf on the side of the Grill Body using four Lock Washers and four
1/2” Hex Bolts.
Hex Bolt
Lock Washer
Side Shelf
