Charmglow 720 - Parts List

26
Model 720-0396 PARTS LIST
REF# Description QTY REF# Description QTY
01 Main Lid 1 48 Door Handle 1
02 Temperature Gauge 1 49 Fix Piece Of Door Shaft 1
03 Logo 1 50 Lighting Rod 1
04 Main Lid Handle Heat Insulating Spacer 4 51 Right Square Pipe Of Front 1
05 Main Lid Handle Heat Insulating Cover 2 52 Right Side Panel 1
06 Hood Buffer 2 53 Right Square Pipe Of Back 1
07 Main Lid Handle Seat 2 54 Tank Heat Shield 1
08 Main Lid Handle Tube 1 55 Inlet Plastic Loop 1
09 Rotisserie Motor 1 56 Back Panel 1
10 Motor Bracket 1 57 Back Frame 1
11 Bowl Assembly 1 58 Firebox Rear Trim Piece 1
12 Grease Box 1 59 Tank Heat Shield Bracket 2
13 Grease Tray 1 60 Side Burner Manifold 1
14 Front Baffle 1 61 Gas Valve, Side Burner 1
15 Gas Valve, Main Burner 5 62 Flex Tube, Side Burner 1
16 Smoke Tray Cover 1 63 Regulator, LP 1
17 Rotisserie Gas Valve 1 64 Fix Piece Of Side Burner 2
18 Side Burner PVC Hose 1 65 Brass Connector Of Side Burner Orifice 1
19 Manifold 1 66 Fix Bracket Of Side Burner 1
20 Manifold Bracket 7 67 Pipe Side Burner 1
21 Control Panel 1 68 Side Burner Body 1
22 Control Knob Seat 7 69 Side Burner Grate 1
23 Smoker Tray 1 70 Side Burner Igniter Wire 1
24 Control Knob 7 71 Cooking Grid, Side Burner 1
25 Left Side Shelf 1 72 Side Burner Lid 1
26 Electric Igniter 1 73 Side Burner Lid Hinge Rod 1
27 Front Panel, Side Shelf 1 74 Control Panel, Side Burner 1
28 Left Side Panel 1 75 Grease Slide Panel I 1
29 Left Square Pipe Of Back 1 76 Grease Slide Panel II 1
30 Left Square Pipe Of Front 1 77 Counter-Balance 1
31 Top Drawer Panel 1 78 Spit Fork 2
32 Front Frame 1 79 Rotisserie Handle 1
33 Magnet 2 80 Key Washer 2
34 Drawer Slide Bracket 2 81 Shaft Collar 1
35 Drawer Slide 4 82 Spit Rod 1
36 Drawer Handle 2 83 Rotisserie Burner Gas Collector 1
37 Upper Drawer Assembly 1 84 Rotisserie Burner 1
38 Bottom Drawer Assembly 1 85 Rear Baffle Of Rotisserie Burner 1
39 Cart Board 1 86 Rotisserie Burner Thermocouple 1
40 Bottom Panel 1 87 Rotisserie Burner Thermocouple Bracket 1
41 Caster With Brake 2 88 Brass Connector Of Rotisserie Burner 1
42 Gas Tank Tray Slide Bracket 2 89 Flex Tube Of Rotisserie Burner 1
43 Right Drawer Slide 2 90 Main Burner 5
44 Gas Tank Tray 1 91 Rotisserie Burner Igniter Wire 1
45 Tank Bolt 1 92 Flame Tamer 5
46 Caster 2 93 Cooking Grid With Hole 3
