InstructionsQuick Start Guide - Cyl-Tel
®
& Tank-Tel
®
Liquid Level Gauges
Cyl-Tel/Tank-Tel Sensor Names
The following tables explain the sensor names used in the
Cyl-Tel/Tank-Tel liquid level gauge rmware on rev. 2.6M
and later. If the Cyl-Tel/Tank-Tel gauge has rev. 2.6M or
later then the sensor name will be printed on the back label
of the gauge for the customer’s reference. The names are
used when selecting the sensor type in the Cyl-Tel/Tank-Tel
gauge menu. For example, if a Cyl-Tel gauge has a brass
block sensor on the back, the sensor needs to be DP4 in the
sensor type in the setup menu.
The tables below give a complete list of sensors currently
compatible with the Cyl-Tel/Tank-Tel liquid level gauges.
Differential Pressure Sensors
Cyl-Tel/Tank-Tel
Sensor Name
Sensor Type Sensor Range
DP1 AST15 415 “H
2
O
DP2 AST7.25 200 “H
2
O
DP3 AST30 830 “H
2
O
DP4 Brass Block 200 200 “H
2
O
DP5 Brass Block 1000 1000 “H
2
O
DP6 Brass Block 2000 2000 “H
2
O
Gauge Pressure Sensors
Cyl-Tel/Tank-Tel
Sensor Name
Sensor Type Sensor Range
OFF None Attached --
GP1 AST 50 Bar 725 psig
GP2 MLH Honeywell 1000 psig
GP3 WIKA 600 psig
