CHART Cyl-Tel - Setting DP Zero; Setting Correct Saturation Pressure; Custom Tank Setup

5
InstructionsQuick Start Guide - Cyl-Tel
®
& Tank-Tel
®
Liquid Level Gauges
8. Use the arrow buttons to highlight the “DP ZERO”
option in the MAIN MENU.
Caution! Make sure the Equalization Valve
is open or set to equalization/
service before setting the DP
ZERO!
9. Press the ‘NEXT’ button to display the current and new
DP ZERO.
10. Press the ‘NEXT’ button again to accept the new DP
ZERO. If you think the number is wrong press the
‘EXIT’ button to cancel the new DP ZERO.
11. At this point you are done. Press the ‘EXIT’ button to
leave the MAIN MENU. The unit will inform you the
SETTINGS CHANGED. Press the ‘SAVE’ button to
save the new settings.
12. Close the equalization valve or rotate the isolation valve
back into normal operation.
Setting DP Zero
1. Press and release the ‘ON’ button to turn on the gauge
display.
2. To access the menu hold the ‘ON’ button for 10-15
seconds. The screen will read “PLEASE WAIT”.
3. Once the “ON” button has been held long enough the
MAIN MENU will display with the “SET TANK”
option highlighted.
4. Use the arrow buttons to highlight the “DP ZERO”
option in the MAIN MENU.
Caution! Make sure the Equalization
Valve is open or set to
equalization/service before
setting the DP ZERO!
5. Press the ‘NEXT’ button to display the current and new
DP ZERO.
6. Press the ‘NEXT’ button to accept the new DP ZERO.
If you think the number is wrong press the ‘EXIT’
button to cancel the new DP ZERO.
7. At this point you are done. Press the ‘EXIT’ button to
leave the MAIN MENU. The unit will inform you that
the SETTINGS CHANGED. Press the ‘SAVE’ button to
save the new settings.
8. Close the equalization valve or rotate the isolation valve
back into normal operation.
Setting Correct Saturation Pressure
1. Press and release the ‘ON’ button to turn on the gauge
display.
2. To access the menu hold the ‘ON’ button for 10-15
seconds. The screen will read “PLEASE WAIT”.
3. Once the “ON” button has been held long enough the
MAIN MENU will display with the “SET TANK”
option highlighted.
4. Use the arrow buttons to highlight the “SET CUSTOM”
option. Press the ‘NEXT’ button to proceed.
5. “SETUP CUSTOM TANK” will appear with the
“LENGTH” option highlighted.
6. Use the arrow buttons to navigate to the “PRESSURE”
option and press the ‘NEXT’ button.
7. The word “SELECT” on the upper left side of the
screen will disappear. You are now able to change the
saturation pressure.
8. Use the Up/Down arrow buttons to change the
saturation pressure of the currently selected tank.
9. Once the desired saturation pressure is set, press the
‘NEXT’ button to select the option. Press the ‘EXIT’
button to exit the menu.
10. The unit will ask if you would like to save changes.
Press the ‘SAVE’ button to proceed out of the menu.
11. The unit will back out to the MAIN MENU. Press the
‘EXIT’ button again to exit the MAIN MENU.
Custom Tank Setup
1. Press and release the ‘ON’ button to turn on the gauge
display.
2. To access the menu hold the ‘ON’ button for 10-15
seconds. The screen will read “PLEASE WAIT”.
3. Once in the MAIN MENU use the arrow buttons to
highlight the “SET CUSTOM” option and press the
‘NEXT’ button to advance to the next screen.
4. This is the custom tank setup menu. The rst option to
input is the overall length of the inner vessel. To enter
this length press the ‘NEXT’ button.
5. When the ‘NEXT’ button is pressed “*” will appear
next to the length. Use the arrow buttons to change the
dimension to the desired length of the inner vessel in
inches “in”.
