Chattanooga Intelect Legend 2 - Table of Contents

| Intelect
®
Legend 2 - Service Manual DOMESTIC 2
CONTENTS
EN
1. INTRODUCTION
1.1. HISTORY P4
1.2. FOREWORD P4
1.3. INTENDED USER PROFILE P4
1.4. INTENDED ENVIRONMENT FOR USE P4
1.5. PRECAUTIONARY INSTRUCTIONS P4
2. GENERAL WARNINGS AND
PRECAUTIONS
2.1. CAUTION P6
2.2. WARNING P7
2.3. DANGER P8
3. DEVICE DESCRIPTION
3.1. GENERAL TERMINOLOGY P10
3.2. SYSTEM SOFTWARE SYMBOLS P10
3.3. DESCRIPTION OF DEVICE MARKINGS P11
3.4. PRODUCT DESCRIPTION P12
3.5. OPERATOR INTERFACE P12
3.6. COMPONENTS P13
3.7. SYSTEM DIMENSIONS & P14
SPECIFICATIONS
3.8. THERAPIES SPECIFICATIONS P15
4. USER INTERFACE
4.1. SOFTWARE VERSION
& SERIAL NUMBER P20
4.2. SCREEN DESCRIPTION P20
4.3. SETTINGS MENU P22
4.4. ADVANCED SETTINGS P22
4.5. SERVICE MENU P23
4.6. SOFTWARE UPDATE P23
4.7. PRINTSCREEN P23
5. MAINTENANCE OPERATION
5.1. GENERAL P24
5.2. SPECIAL TOOLS, FIXTURES & P24
MATERIALS REQUIRED
5.3. EQUIPMENT REQUIRED P24
5.4. RECIPE FOR DEGASSED WATER P24
5.5. FULL FUNCTIONAL TESTS P24
5.6. US CALIBRATION REQUIREMENTS P24
5.7. US CALIBRATION PROCEDURE P25
5.8. CLEANING INSTRUCTION P27
6. TROUBLESHOOTING
6.1. NO POWER P29
6.2. SCREEN DEFAULT P30
6.3. FAN DEFAULT P30
6.4. BATTERIE TEST P31
6.5. FAILURE DURING TREATMENT P31
6.6. ERRORS CODES P31
7. REPAIR OPERATION
7.1. TOOLS & EQUIPMENTS TO REPAIR P33
7.2. BOTTOM OF THE DEVICE P34
7.3. SEPARATING TOP & LOWER ASSEMBLY P35
7.4. TOP SUB ASSEMBLY P36
7.5. LOWER SUB ASSEMBLY P39
7.6. REASSEMBLY P42
7.7. US APPLICATOR P43
8. FINAL TEST
8.1. LIST OF MATERIAL P45
8.2. SETUP FOR FINAL TEST P46
8.3. FINAL TEST IL2 P57
8.4. FINAL TEST US APPLICATOR P59
9. EXPLODED VIEWS and
SERVICE PART LISTS
9.1. INTELECT LEGEND 2 P63
9.2. DEVICE TOP SUB ASSEMBLY P64
9.3. TOP DISPLAY SUB ASSEMBLY P65
9.4. LOWER SUB ASSEMBLY P66
9.5. COMBO 2CH LOWER SUB ASSEMBLY P68
9.6. COMBO 4CH LOWER SUB ASSEMBLY P70
9.7. US APPLICATOR P72
9.8. CART 6 BINS P73
