EXPLODED VIEWS AND SERVICE PARTS LISTS
EN
| Intelect
®
Legend 2 - Service Manual DOMESTIC 71
EXPLODED VIEWS and SERVICE PART LISTS
ITEM N° Service part n° Description Qty
1 SP-14-3739 SERVICE PART IL2 4CH MAIN BODY WHITE
1
2 SP-14-3794 SERVICE PART IL2 4CH FRONT LIP WHITE EXTENDED 1
3 SP-14-3797 SERVICE PART IL2 4CH US-STIM RIBBON CABLE
1
4
SP-14-3801 SERVICE PART IL2 ORANGE LIGHT PIPE STIM 3 x5 1
5
SP-14-3802 SERVICE PART IL2 RED LIGHT PIPE STIM 4 x5 1
6
SP-G16-4271
SERVICE PART G16 GREEN LIGHT PIPE STIM 2 x5
1
7
SP-G16-4261
SERVICE PART G16 BLUE LIGHT PIPE STIM 1 x5
1
8
SP-G16-4251
SERVICE PART G16 LIGHT PIPE CYAN US-R x5
1
9
SP-G16-4241
SERVICE PART G16 LIGHT PIPE CYAN US-L x5
1
10 SP-14-3792 SERVICE PART IL2 4CH FRONT PANEL BLACK
1
11
SP-14-3795 SERVICE PART IL2 4CH FAN BRACKET 1
12
14-1044-SP SERVICE PART M4X8 TORX SCREW x 5
2
13
SP-14-3796 SERVICE PART IL2 4CH FAN AIR FLOW GUIDE 1
14
14-1043-SP SERVICE PART M3X8 TORX SCREW x 5
4
15
SP-G16-0021 SERVICE PART STIM IL2 PCBA
2
16
SP-14-3799 SERVICE PART IL2 PCB METAL SPACER 33MM x5
4
17
SP-G16-0031 SERVICE PART ULTRASOUND IL2 PCBA
1
18
G16-2011-SP SERVICE PART MOB2 PCB METAL SPACER 18 MM M3 X 5
4
19 SP-G16-0053 SERVICE PART IL2 4CH CONNECTORS PCBA 1
20
14-1040-SP SERVICE PART KB30X6 PLASTIC TORX SCREW x 5
4
