EXPLODED VIEWS AND SERVICE PARTS LISTS
EN
| Intelect
®
Legend 2 - Service Manual DOMESTIC 74
EXPLODED VIEWS and SERVICE PART LISTS
ITEM N° Service part n° Description Qty
1
27208-SP
SERVICE PART EXPERIA SCREW, # 12 X 5/8, PHIL HEAD x5 4
2 G16-4191-SP
SERVICE PART MOB2
CART TOP BODY WHITE
1
3 G16-4201-SP
SERVICE PART MOB2 CART TOP HANDLE OUTER WHITE
1
4 14-1049-SP SERVICE PART KB30X12 SCREW TORX DRIVE x 5 14
5 27044-SP CART BIN SPACER EPR* 12
6 27043-SP1 SERVICE PART MOB2 CART BIN WHITE RAL9003* 6
7 G16-6021-SP SERVICE PART MOB2 WHITE CART EXTRUSION CHATT LOGO 1
8 G16-6022-SP SERVICE PART MOB2 WHITE CART EXTRUSION NO LOGO
1
9 28735-SP CASTER 3" BLK W/O BRAKE* 2
10 28734-SP CASTER 3" BLK W/LOCKING BRAKE* 2
11 G16-4232-SP SERVICE PART G16 CART BASE PLATE W* 1
12 27209-SP SERVICE PART SCREW #12X1-1/2 PHIL P HD TAP x5 4
