4.7 Screen Memorisation
The key allows 8 or 12 displays to be saved (according to the instrument model) for recall or display later on.
■■
■■
■ A long press (about 3 s) on this key freezes the current screen:
The icon is displayed as soon as the operation has
finished.
This icon is replaced by if there is no space left in the
memory to record the photo.
Note: These screens can be stored on a PC via the
QualiStartView operating software.
■■
■■
■ A short press (about 1 s) on this key gives access to the menu of screens already saved:
The selection of the screen to be displayed (or erased) is carried
out using the and keys
To display the screen selected, press on then on the
validation key.
To delete the screen selected, press on then on the
validation key.
To exit from the display of the recorded screen and return to the display of the recorded screen menu, press the key
again.
Important note: the various storage spaces of C.A 8332B and C.A 8334B are of a fixed size and are completely independent of
one another (partitioned). There are 4 spaces for C.A 8334B (alarms, photographs, transient states and recordings) versus 3
for C.A 8332B (less the transient states).
