3
Fixed Rails
This section describes how to mount the appliance in a rack with fixed rails.
Important - Two people are required to install the appliance in a rack
to prevent any possible damage.
Rack Mounting Hardware and Tools
You must install rack mounting hardware on the appliance before you mount it
in a rack.
Hardware
Qty. Use
Ear mount bracket 2 Attaches to the appliance front panel. Both ear
mount brackets are identical.
Ear mount screws 6 Secures the ear mount brackets to the appliance
front panel. These screw heads are smaller (5
mm).
Appliance rail 2 Attaches to the appliance. Both rails are
identical.
Rail plates 2 Attaches to the appliance rails. Both plates are
identical.
Appliance rail
screws
14 Secures the rail plates to the appliance rails and
the rails to the appliance. These screw heads are
larger (8 mm).
