Chery QQ3 - Airflow Distribution Switch

Ventilation and A/C system
74
Airflow distribution
switch
Airflow distribution switch is used to
select airflow direction. There are five
positions for switch:
Head
Head and foot
Foot
Foot/defrost
Defrost
" head" position(
)
Air flows out from center ventilation
opening and side ventilation opening.
" head and foot" position( )
Air flows out from center ventilation
opening and front bottom exhaust
opening.
" foot" position ( )
Air mostly flows from front bottom
exhaust opening.
" foot / defrost" position(
)
Air flows out from front bottom exhaust
opening, windshield defrosting
ventilation opening and front windshield
defrosting ventilation opening.
" defrost" position(
)
Air flows out from windshield defrosting
ventilation openings and front windshield
defrosting ventilation openings.
