2001
Chevrolet Corvette Restoration Kit
Trans Mount to Transmission
Bolt
25N·m
181b ft
Transmission
Fluid Pressure Manual Valve Position Switch to
8.0-14.0 N·m 6-101bft
Valve
Body Bolt
Transmission Oil Cooler Pipe Fitting
35.0-41.0 N·m 26-30
Ib
ft
Iransmission
Oil Pan to Case Bolt 9.5-13.8 N·m 7-101bft
Transmission to EnQine Bolt
47N·m
351b ft
Valve Body to Case Bolt
8.0-14.0 N·m 6-10
Ib
ft
Transmission General Specifications
Weight
Dry
(Approximate)
r,.",",rnl"''''''~n
Weight
Wet
(Approximate)
Fluid Capacity Specifications
Transmission Component and System Description
The 4L60E transmission consists primarily
of
the following components:
• Torque converter assembly
• Servo assembly
and 2-4 band assembly
•
Reverse input clutch and housing
• Overrun clutch
•
Forward clutch
• 3-4 clutch
Page 83
To Next Page
