Chevrolet sonic 2016 - Page 251

Chevrolet Sonic Owner Manual (GMNA-Localizing-U.S/Canada-9085902) -
2016 - CRC - 5/27/15
250 Vehicle Care
Mini Fuses Usage
16 Washer
17 Fuel Pump (1.8L)
18 Engine Control
Module 5
19 Fuel System Control
Module 2/Leveling
20 Transmission Control
Module 1
21 Engine Control
Module 1
22 Coil
23 Engine Control
Module 4
24 Engine Control
Module 3
25 Engine Control
Module 2
26 Injector/Ignition Coil
27 Engine Control
Module
28 Air Conditioning
Compressor Clutch
Mini Fuses Usage
29 Transmission Control
Module
30 Horn
31 Front Fog Lamps
32 Left High Beam
33 Right High Beam
SPARE Spare
J-Case
Fuses
Usage
1 Antilock Brake
System Pump
2 Front Wiper
3 Blower
4 Run/Crank IEC
6 Cooling Fan K5
7 Cooling Fan K4
8 EVP
9 Start
Relays Usage
RLY 1 Front Wiper Control
Relay
RLY 2 Front Wiper Speed
Relay
RLY 3 Rear Window Defogger
Relay
RLY 4 Run/Crank Relay
RLY 6 Fuel Pump Relay (1.8L)
RLY 7 Cooling Fan K2
Relay (1.4L)
RLY 8 Cooling Fan K3 Relay
(1.8L), Cooling Fan K3
High Current
Relay (1.4L)
RLY 9 Powertrain Relay
RLY 10 Start High Current
Relay
RLY 11 Air Conditioning
Compressor Clutch
Relay
RLY 12 High-Beam Relay
RLY 13 Cooling Fan K1 Relay
