98 Instruments and controls
<Type 2>
GC3N5004A
Date, time, outside temperature and
infotainment system information are
displayed.
When infotainment system is on,
settings for vehicle personalisation
are displayed.
See Vehicle personalization on page
102.
Vehicle messages
Vehicle messages
The messages are given via the
Driver Information Center (DIC) or as
warning chime.
Depending on vehicle equipment and
vehicle personalization some of the
functions described below might not
be available.
GC3N5011A
The vehicle messages are displayed
as code numbers.
Caution
If the vehicle message is shown,
have the vehicle checked by a
repairer immediately.
No. Vehicle message
15 High mounted brake light
failure
16 Service brake lights
18 Left low beam failure
20 Right low beam failure
21 Left front position light failure
22 Right front position light
failure
