Vehicle care 251
Rear wiper blade
GO3E10060A
1. Remove the wiper cover from the
wiper assembly.
2. Lift wiper blade up to plane.
GO3E10061A
3. Press slider holder pin with
fingers.
4. Pull wiper blade out.
Bulb replacement
Bulb replacement
Switch off the ignition and switch off
the relevant switch or close the
doors.
Only hold a new bulb at the base! Do
not touch the bulb glass with bare
hands.
Use only the same bulb type for
replacement.
Replace headlight bulbs from within
the engine compartment.
Note
After driving in heavy rain or
washing, some exterior lamp
lenses could appear frosty.
This condition is caused by the
temperature difference between
the lamp inside and outside.
Caution
Do not allow the wiper arm to
fallagainst the windshield, since it
maychip or crack the
windshield.Always slowly lower it
down.
