2.8 Symbols on the product
The following symbols can be found on the
HAWK PEN, its accessories or its packaging:
Symbol Meaning
Satisfies the requirements
of directives 2006/42/EC
(machinery directive) and
2004/108/EC (EMC directive)
Observe instructions for use!
Manufacturer
Date of manufacture
Catalogue number
N
Serial number
Batch code
Sterilised with ethylene oxide
Use-by date
Attention!
Temperature limit
Humidity limit
Store in a dry place
Fragile
Cannot be use if packaging is
damaged
Do not reuse!
Dispose of properly as used
electronic equipment!
3 Scope of delivery
1 Cheyenne HAWK PEN one-inch
1 HAWK PEN TRAY
1 Starter kit with various safety
cartridges
1 Power cable
1 Cable adapter (6.3mm jack to 3.5mm
socket)
1 Maintenance kit with replacement
O-rings
1 Operating instructions
4 Product info about the HAWK
PEN
The Cheyenne HAWK PEN is a high-
performance device and is much quieter
and vibrates less than conventional
tattooing machines. It has powerful skin
piercing power and frequency.
4.1 Technical data
Nominal voltage 6 to 12.6 V DC
Power intake 4 W
Start-up current
Max. 2.5 A for
max. 200 ms
Piercing frequency 70 to 160 Hz
Stroke 3.5 mm
Needle protrusion 0 to 4.5 mm
Electrical connection 3.5 mm jack
Drive Precision motor
– DC
Operating mode Continuous
operation
Diameter 25.4 mm
Length 123 mm
Weight Approx. 130 g
Cheyenne HAWK PEN
