240 VOLT ARC/TIG
INVERTER WELDER
AND TIG WELDING TORCH
Model
66787
SET UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright
©
2009 by Harbor Freight Tools
®
. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 09h, 09k, 09l

Table of Contents

Questions and Answers

  • G
    Gabrielle VasquezJul 29, 2025
    Why Chicago Electric Welding System won't turn on?
    • M
      Mary DawsonJul 29, 2025
      The Chicago Electric Welding System might not be turning on due to several reasons: there may be no power at the electrical outlet, the power cord may not be properly connected, or the line voltage might be incorrect. First, check the power at the electrical outlet. Next, ensure that the power cord is securely plugged in. Finally, verify that the welder is connected to a 240VAC electrical outlet.
  • J
    Jessica BradleyAug 3, 2025
    What to do if there is no weld output with high temperature light on Chicago Electric 66787 Welding System?
    • M
      Melody CruzAug 3, 2025
      If there's no weld output and the high-temperature light is on, it could be due to several reasons. The welder may have overheated, so allow the unit to cool down with the fan on. Alternatively, the duty cycle or amps might be too high, so reduce them. Lastly, airflow might be blocked; clean the vents and fan with compressed air.
  • V
    Vanessa SmithAug 8, 2025
    How to fix erratic arc on Chicago Electric Welding System?
    • C
      Carrie FryeAug 8, 2025
      An erratic or improper arc or welding output can be caused by bad connections, incorrect polarity, or a dirty workpiece. To resolve this, clean and tighten all connections. Ensure that the polarity is correctly connected. Thoroughly clean the workpiece.
  • G
    grantdennisAug 13, 2025
    What to do if Chicago Electric 66787 has no weld output with ready light on?
    • S
      Samuel FoleyAug 13, 2025
      If there is no weld output but the ready light is on, it could be due to a loose weld cable or an improper ground clamp connection. Ensure the weld cable connection at the welder is tightened. Also, make sure the area where the ground clamp is attached is clean, exposed metal, and free of dirt, paint, and oil.
  • D
    David MejiaAug 18, 2025
    How to troubleshoot a Chicago Electric 66787 Welding System fan that is not operating?
    • R
      Richard WilsonAug 19, 2025
      If the fan is not operating, there might be an obstruction, the fan could be dirty, or it may have burnt out. First, remove any obstruction blocking the fan. If that doesn't work, clean the fan with compressed air. If the fan is still not working, have it replaced by a qualified service technician.
  • J
    Jeffery CombsAug 25, 2025
    Why does the main supply fuse shut off frequently on my Chicago Electric 66787?
    • T
      Tanya DiazAug 25, 2025
      The main supply fuse might be shutting off frequently because the circuit breaker has too low amperage. Install a dedicated 25 amp circuit breaker to resolve this issue.

Summary

IMPORTANT SAFETY INFORMATION

General Safety Rules

General safety guidelines to prevent electric shock, fire, and serious injury.

Personal Safety

Ensures alertness, proper attire, and safe practices to avoid personal injury.

Power Tool Use and Care

Guidelines for safe operation, maintenance, and storage of power tools.

Specific Safety Rules

Detailed safety precautions for welding, electrical hazards, and fire prevention.

Specifications

Unpacking

Tig Torch Assembly

Welder Features

Operating Instructions

Tool Set Up

Steps for preparing the welder and connecting cables before operation.

Work Piece and Work Area Set Up

Ensures a clean, safe, and organized environment for welding operations.

General Operating Instructions

Covers essential steps for setting up and performing arc welding.

Tig Torch Operating Instructions

Step-by-step guide for setting up and using the TIG torch for welding.

Maintenance and Servicing

Troubleshooting

Welder Parts List and Assembly Diagram

Tig Torch Parts List and Assembly Diagram

Limited 90 Day Warranty
