SKU 67537 For technical questions, please call 1-800-444-3353. Page 12
PARTS LIST
Part Description Qty
1 Socket Head Screw M8 x 1.25 x 12 1
2 Flange 1
3 Spindle 1
4 Rubber Casing 1
5 Circlip 1
6 Spring Washer 1
7 Bearing 6000 1
8 Block 1
9 Bushing 1
10 Screw ST4 x 25 4
11 Housing Head 1
12 Circlip 1
13 Bearing 625 1
14 Washer 1
15 Cover 1
16 Bearing 608 1
17 Washer 1
18 Armature 1
19 Bearing 607 1
20 Bushing 1
21 Guide 1
Part Description Qty
22 Screw ST4.0 x 55 2
23 Stator 1
24 Power Switch 1
25 1
26 Plastic Housing 1
28 Brush Holder 2
29 Carbon Brush 2
30 Rivet 4
31 Screw ST4.0 x 12 2
32 Rear Housing (left) 1
33 Switch 1
34 Brace 1
35 Clip 1
36 Screw ST3.0 x 8 2
37 Power Cord 1
38 Rubber Sleeve 1
39 Speed Dial 1
40 Rear Housing (right) 1
41 Screw ST4.0 x 25 1
42 Screw ST4.0 x 32 2
PLEASE READ THE FOLLOWING CAREFULLY
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
